库号：D409867

电源电压(v/Hz)voltage
AC220/50
真空泵电机功率(W)Motor Power
1000
热封功率(W)Sealing Power
500
真空室低压强(Kpa)Ultimate Vacuum Pressure
1
每室热封条数(pcs)No.of Sealing Bars for Each Chamber
2
真空室内尺寸(LxWxH)(mm)Chamber Dimension
435*420*75
热封条长度(mm)Sealing Length
400
热封宽度(mm)Sealing Width
10
真空泵排气量(m3 /h) Vacuum Pump Rate
20
真空室材质Materialfor Vacuum Chamber
不锈钢Stainless steel
201
外形尺寸(LxWxH)(mm)Dimension
540*490*950
净重(kg)Net Weight
62
两条封口之间的距离(mm)The center distance between
370
two sealing bars

电源电压(v/Hz)voltage
AC220/50
真空泵电机功率(W)Motor Power
1000
热封功率(W)Sealing Power
500
真空室低压强(Kpa)Ultimate Vacuum Pressure
1
每室热封条数(pcs)No.of Sealing Bars for Each Chamber
2
真空室内尺寸(LxWxH)(mm)Chamber Dimension
435*420*75
热封条长度(mm)Sealing Length
400
热封宽度(mm)Sealing Width
10
真空泵排气量(m3 /h) Vacuum Pump Rate
20
真空室材质Materialfor Vacuum Chamber
不锈钢Stainless steel
201
外形尺寸(LxWxH)(mm)Dimension
540*490*950
净重(kg)Net Weight
62
两条封口之间的距离(mm)The center distance between
370
two sealing bars
